Micro-Processed Lock-Out Relay Module for PARALLAX SYSTEM 10LO21P by BEA

SKU:
10LO21P
  • Usually Ships 4 to 7 Business Days
MSRP: $101.13
$91.94
(You save $9.19 )
Adding to cart… The item has been added
  • Shipping Cost? For the cost of shipping your item please add the item into the shopping cart. Once the part is in the cart fill out address information in the cart under the Shipping area in the Summary section. Our system will then calculate the shipping fee based on your location and the weight of the product. This is all done before you are asked to provide payment information.

North Shore Commercial Door has the 10LO21P Lock-Out Module for PARALLAX PACKAGES by BEA. The 10LO21P is a micro-processed lockout module designed to operate on swing door applications with BEA's Bodyguard overhead presence sensor when used with the complete PARALLAX System. The Lock-Out module locks out header-mounted safety sensors while the door is in closing cycle. The 10LO21P interprets door open or door closed positions by reading the motor voltage input. The 10LO21P communicates the position of the door based on the motor voltage information to the Bodyguard or DK12 via data lines. The 10LO21P provides optional safety beam input to override the inhibit signal during closing. For example, when the safety beam path is blocked or interrupted during closing, the inhibit data will be cancelled, thus initiating a safety signal to the door control safety input.

***Please Note: This is the standard lockout module required by the following Swing Door Activation & Safety Systems by BEA:

Product Highlights:

  • Item Number: 10LO21P
  • Micro-processed lockout module
  • Operates on swing door applications with the Bodyguard overhead presence sensor when used with the complete PARALLAX System
  • Locks out header-mounted safety sensor while the door is in closing cycle
  • Interprets position of the door by reading the motor voltage
  • Communicates the position of the door to the Bodyguard via data lines
  • Provides optional safety beam input to override the inhibit signal during closing
  • When safety beam path is blocked or interrupted during closing, the inhibit data will be cancelled, thus initiating a safety signal to the door control safety input

​Technical Information:

  • Power Supply: 12-24 Volts AC / 15-24 Volts DC
  • Operating Frequency: 4 MHz (Microprocessor)
  • Power Consumption: 10 mA at rest, 50 mA Max.
  • Output: SPST Relays
  • Max. Voltage - Relay Contact: 60V DC, 120V AC
  • Max. Current - Relay Contacts (both): 2A DC, 0.5A AC

10LO21P-UG.pdf
