LiftMaster Circuit and Logic Boards

In order for your Chamberlain LiftMaster system to run at its best, the circuit board needs to be in good shape. Unfortunately, these components are exposed to constant wear and use, so they do occasionally need to be replaced. North Shore Commercial Door has all the LiftMaster garage door opener circuit boards required to keep your opener operating well. These logic boards can be replaced relatively easily and are a great choice for those who want to save the money and hassle associated with a whole-system garage door opener replacement.

If you've noticed that your garage door opener isn't responding to your remote or keypad, there could be a problem with the circuit board. Once you perform some troubleshooting and determine for sure that it's a logic board issue, you'll want to find the right replacement board. On the bottom of this page, you'll find a variety of helpful resources to assist you with finding the appropriate LiftMaster logic board for your model. You'll find a handy diagram that will allow you to easily find the model/serial number label on your LiftMaster residential door opener as well as a list of parts that will help you find the right Chamberlain garage door opener logic board.

There's no doubt about it: replacing Chamberlain circuit boards can add years of life to your LiftMaster garage door opener, and the process has never been easier or more affordable than with the help of North Shore Commercial Door. Browse our range of circuit and logic boards to find the product that works with your system. If you are unsure which board to choose or need assistance finding a style not listed here, you can always contact us for one-on-one advice. Our team of experts is well-equipped to help you find the parts you need to keep your LiftMaster in play for years to come.



Operators Built from 1993-1997
Billion Code with Safety Sensors
MFG. DATE DELUXE CHAIN OR BELT DRIVE STANDARD CHAIN DRIVE SCREW DRIVE

1993 41A4252 41A4252-1 N/A
1993 41A4252-4 41A4252-5 N/A
1993 41A4252-6 41A4252-7 N/A
1994 41A4252-6A 41A4252-7A N/A
1995 41A4252-6B 41A4252-7B N/A
1996 41A4252-6C 41A4252-7C 41D4674-1C
1996-2004 41A4252-6D 41A4252-7D 41D4674-1D
2004 41A4252-6E 41A4252-7E 41D4674-1E
2005 41A4252-6F 41A4252-7F 41D4674-1F
Current 41A4252-6G 41A4252-7G 41D4674-1G
If you have a board on the list above, replace it with:
41A4252-6 41A4252-7G 41D4674-1

Operators Built from 1997-Current Security +
MFG. DATE CHAIN DRIVE DELUXE ENDPANEL CHAIN DRIVE STANDARD ENDPANEL CHAMBERLAIN SCREW DRIVE

1997 41A5021 41A5021-1 41D4674-14
1998 41A5021-B 41A5021-1B
1999 41A5021-C 41A5021-1C
1999 41A5021-D 41A5021-1D 41D4674-14D
2000 41A5021-E 41A5021-1E 41D4674-14E
2003 41A5021-F 41A5021-1F 41D4674-14F
2003-2005 41A5021-G 41A5021-1G 41D4674-14G
2004 41A5021-H 41A5021-1H
2005 41A5021-I 41A5021-1I 41D4674-14H
If you have a board on the list above, replace it with:
41A5021-I 41A5021-1I 41D4674-14H
MFG. DATE LIFTMASTER SCREW DRIVE BELT DRIVE LIFTMASTER LOW PROFILE

1997 41D4674-10
1998
1999 41D4674-10C
1999 41D4674-10D 41A5021-D
2000 41D4674-10E 41A5021-5E 41A5389-1
2003 41D4674-10F 41A5021-5F 41A5389-1C
2003-2005 41D4674-10G 41A5021-5G 41A5389-1D
2004 41A5021-5H
2005 41D4674-10H 41A5021-5I 41A5389-1E
If you have a board on the list above, replace it with:
41D4674-10H 41A5021-5I 41A5389-1E

Operators Built from 2001-2005 Security +
MFG. DATE AC CHAIN DRIVE DELUXE ENDPANEL CHAIN DRIVE STANDARD ENDPANEL AC BELT DRIVE

2001-2002 41A5483 41A5483-1 41A5483-4
2003- 2005 41A5483B 41A5483-1B 41A5483-4B
MFG. DATE DC BELT DRIVE UNITS WITHOUT BATTERY BACK-UP DC BELT DRIVE UNITS WITH BATTERY BACK-UP

2001-2002 41A5507
2003- 2005 41A5507B 41A5507-6

Operators Built from 2005-Current 315MHz Security +
MFG. DATE AC CHAIN DRIVE DELUXE ENDPANEL AC CHAIN DRIVE STANDARD ENDPANEL AC BELT DRIVE

2005-Current 41AC050-2 1/2 HP 41AC050-1 41AB050-2
  41AC075-2 3/4 HP
DC BELT DRIVE UNITS DC JACKSHAFT MODEL 3800 CHAIN DRIVE "CONTRACTOR" SERIES LOW PROFILE SCREW DRIVE

41DB001-1 41DJ001 41A5021-1H-315 41AS050-1
