BEA LZR-WIDESCAN OMNI Time-of-Flight Laser Sensor |
BEA LZR-WIDESCAN OMNI Time-of-Flight Laser Sensor is the premium tier BEA traffic/object/pedestrian sensor. With a built in power-logic module and seven distinct laser motion curtains, this is an all purpose, industrial-door-rated motion, presence and safety sensor. Monitors for various and programable motions using angled IR broadcast fields. 2 solid-state relays available for programming in of satellite/slave units. Uses a unique canopy-style multi-angled detection field. NEMA 4 housing w/ IP65 means housing it maximum dust, weather-borne and workshop-particulate resistant. Also means it is rated for moderate direct-contact with sprayed/splashed water. So it will work in a host of interior and awning, covered-exterior settings. Truck docks, ground level logistics, freight, warehousing, sanitation, municipal settings and similar applications. Warehouse to your house, all entryway needs found at North Shore Commercial Door. LZR-WIDESCAN OMNI means no hassle with the time, planning, configuration and material-intense process of asphalt or concrete cutting and laying of loops.
PRODUCT HIGHLIGHTS | SPECS | TECHS
- Infra-red laser scanner for opening, sensing and presence detection of industrial-class doors
- LASER, time-of-flight measurement tech
- Built-in solid-state relays allow for automatic actions for door as open, close, halt
- Safety for vehicles, perimeter monitoring
- 3 progressively sensitive fields of detection
- outermost: motion
- middle: presence
- innermost: safety
- Can work for doors up to 19 ft in height
- Engineered for long-lasting performance in industrial, commercial freight and countless other applications requiring a adjustable, specified safety sensing
- Installer-friendly programming module
- Up/down/toggle directional buttons for use with built-in LCD programming
- Select button w/ separate reverse/go back button
- Can also be programmed with the BEA Eagle, Bodyguard, DK-12, Iris, Falcon, and the Wizard Motion Detector Universal Remote 10REMOTE
- Works in cold environments and has built-in heating function
- Detection field max width: 1.2 x of mounting height
- Detection field max depth: 1.2 x of mounting height (adjustable)
- Maximum output pulse power 75 W
- Typical Response time: 0.1 seconds
- 2 tri-color LEDs for monitoring, function, maintenance and install feedback
- Rated NEMA 4 / IP65
- Polycarbonate/ASA housing
- Supply Voltage: 12 – 24 VAC +/- 10% | 12 – 30 VDC +/- 10% @ sensor terminal
- Input: 30 VDC (max. switching voltage) low < 1 V high > 10 V (voltage threshold)
- Power Consumption: < 2.5 W (heating: off) < 15 W (heating: eco or auto)
