Guardian MODEL 628 PRO SERIES Garage Door Opener HPe DC 7TG628D
Guardian MODEL 628 PRO SERIES Garage Door Opener  HPe DC 7TG628D
Product Description

The PRO SERIES Model 628 Garage Door Operator by Guardian is now available from North Shore Commercial Door. Enjoy the quiet confidence of the reliable DC motor. The smooth and quiet motor makes it an ideal choice for home owners with a bedroom above the garage. Guardian's most powerful DC motor provides added power to lift heavier doors. Their advanced, steel-enclosed, water-resistant, photo-eye system ensures the highest degree of reliability in detecting obstructions during operation.

IMPORTANT ORDERING & PRICING INFORMATION

  • 7 FT or 8 FT DOOR HEIGHT Options:
  • The listed price of $362.60 is the standard, 7 FT DOOR HEIGHT ONLY
  • The listed price of $362.60 will be increased by $12.00 for the 8 FT DOOR HEIGHT
  • To specify preferred DOOR HEIGHT, please select from the following options in the drop-down menu above:
    • 7 FT
    • 8 FT Add(+$12.00)
  • FULL CHAIN DRIVE or GLASS FIBER REINFORCED BELT DRIVE Options:
  • The listed price of $362.60 is the standard, CHAIN DRIVE ONLY
  • The listed price of $362.60 will be increased by $33.60 for the BELT DRIVE
  • To specify preferred DRIVE STYLE, please select from the following options in the drop-down menu above:
    • CHAIN
    • BELT Add(+$33.60)

PRODUCT HIGHLIGHTS

  • Item Number: 7TG628D
  • PRO SERIES Model 628 Garage Door Operator by Guardian

PERFORMANCE

  • ¾ HPe* 120V/60Hz AC motor
  • Available with a heavy-duty chain or durable belt drive
  • One-piece T-rail
  • Maintenance-free power train and rail system does not require periodic lubrication
  • 200w courtesy light
  • 5-year motor warranty and 1-year parts warranty

*Meets Guardian's lifting force specification for ¾ HP garage door opener

FEATURES

Photo-Eye Safety System

  • Infra-red photo eyes
  • Steel-enclosed
  • Water-resistant
  • Heavy-duty brackets for added stability
  • Reliably reverses the door if the beam is broken

Radio Controls

  • Stable radio code enables radio controls to program to all HomeLink® systems
  • Fixed coding system with over 4 million coding combinations
  • 303 MHz frequency
  • 200 FT operating range (tested)
  • 20 code registers
  • 12V A23 standard remote-control battery

Safety Features

  • Down safety reversal
  • Up safety stop
  • Emergency quick release
  • Pet / Ventilation Opening
  • Soft-start & stop electronic learn limits

STANDARD ACCESSORIES (INCLUDED)

Deluxe Door Control Console

  • Open your door, turn on your lights, and set remote security lock-out from one convenient location

2-Button Remote Control

  • Comes with a convenient visor or wall mount
  • Small enough to fit in your pocket or purse
  • Open up two Guardian garage door openers

OTHER TECHNICAL INFORMATION

Electrical/Motor

  • Current: 4A
  • Power Cord: 48-inch, 3-prong
  • ETL Listed to UL 325: Yes

Lighting

  • Number of Bulbs: 2
  • Total Wattage: 200W
  • Delay Duration: 4.5 Minutes

Rail & Drive

  • Material: Steel
  • Type: One-piece T-rail
  • Drive: Full chain or glass fiber reinforced belt pre-tensioned at the factory
  • Lengths: 7FT or 8FT

Installation

  • Headroom Clearance Required: 2 inches
  • Installed Length (std. T-rail): 123.5 inches
  • Max. Door Opening (std. rail): 7'2"
  • Travel Speed: 5.8 in/s
  • Limit Setting: Electronic
  • Force Setting: Electronic auto-learn

Shipping Dimensions

  • Powerhead: 24.5" x 12" x 8"; 17 lbs.
  • Std. 7' Door, T-rail, Chain: 123" x 3.2" x 1.6; 17lbs.
  • Std. 7' Door, T-rail, Belt: 123" x 3.2" x 1.6; 14 lbs.
